DL0502S5低容TVS，用于 ESD和CDE防御 SOT-523封装

ESD Suppressors / TVS Diodes

2-LINE 5V SC75 RClamp0502B Ultra-Low Capacitance TVS for ESD and CDE Protection

功能

峰值脉冲功率Peak pulse power (tp = 8/20μs): 80W

峰值脉冲电流Peak pulse current (tp = 8/20μs): 5A

静电智商测试

· IEC 61000-4-2 (ESD) ±15kV（空气），±8kV（战役）

· IEC 61000-4-4 (EFT) 40A (5/50ns)

责任电压Reverse Stand-off Voltage: 5V

击穿电压Reverse Breakdown Voltage (Min.): 6V

走电流Reverse Leakage Current: 0.5uA

钳位电压Clamping Voltage ( IPP=4A tp=8/20us ): 13V

结电容Junction Capacitance (VR=0V, f = 1MHz Between I/O pins): 0.6pF

固态硅雪崩技能

封装Package: SOT-523
